ASUS PRIME B760M-A Micro ATX Motherboard - LGA 1700, Intel B760, DDR5, PCIe 4.0, Dual M.2
Guarantee Safe Checkout
The ASUS PRIME B760M-A motherboard is designed for users looking to build a powerful and efficient system using Intel's 12th and 13th Generation processors. Built on the Intel B760 chipset, this Micro ATX motherboard supports advanced connectivity options and high-performance features tailored for both gaming and productivity.
Key Features:
- Socket Type: LGA 1700
- Chipset: Intel® B760
- Form Factor: Micro ATX (9.6 x 9.6 inches / 24.4 x 24.4 cm)
CPU Support:
- Compatible with Intel® 12th and 13th Generation Core™, Pentium Gold, and Celeron processors.
Memory Support:
- Slots: 4 x DIMM
- Maximum Capacity: Up to 128GB
- Supported Memory Types: DDR5 (up to 7200+(OC), with support for various lower frequencies down to 4800 MHz)
- Memory Architecture: Dual Channel with support for Intel® Extreme Memory Profile (XMP) and ASUS OptiMem II technology for improved stability.
Expansion Slots:
- 1 x PCIe 4.0 x16 slot (supports x16 mode)
- 1 x PCIe 4.0 x16 slot (supports x4 mode)
- 1 x PCIe 4.0 x16 slot (supports x1 mode)
Storage Options:
-
M.2 Slots:
- 2 x M.2 sockets (supporting PCIe 4.0 x4 and SATA modes)
-
SATA Ports:
- 4 x SATA III (6Gb/s) ports with RAID support.
Networking:
- LAN Controller: Realtek® 2.5Gb Ethernet for high-speed wired connectivity.
Video Outputs:
-
Supports dual video outputs including:
- DisplayPort (up to 8K @ 60Hz)
- Dual HDMI™ ports (up to 4K @ 60Hz)
USB Connectivity:
-
Rear USB Ports:
- Multiple USB ports including USB 3.2 Gen 2 Type-A and front USB Type-C for fast data transfer.
Audio Features:
- Audio Codec: Realtek ALC897 supporting up to 7.1-channel high-definition audio with premium capacitors for enhanced sound quality.
Additional Features:
- Comprehensive Cooling Solutions: Includes VRM heatsinks, M.2 heatsink, PCH heatsink, hybrid fan headers, and Fan Xpert for optimized thermal management.
- Aura Sync RGB Lighting for customizable LED effects that can sync with other compatible components.
