ASUS ProArt Z790-Creator WIFI ATX Motherboard - LGA 1700, Intel Z790, DDR5, PCIe 5.0, Wi-Fi 6E

The ASUS ProArt Z790-Creator WIFI motherboard is specifically designed for content creators and professionals seeking high performance and extensive connectivity. Built on the Intel Z790 chipset, this ATX motherboard supports Intel's 12th and 13th Generation processors and offers advanced features tailored for demanding workloads.

Key Features:

• Socket Type: LGA 1700
• Chipset: Intel® Z790
• Form Factor: ATX (305 x 244 mm)

CPU Support:

• Compatible with Intel® 12th and 13th Generation Core™, Pentium Gold, and Celeron processors.

Memory Support:

• Slots: 4 x DIMM
• Maximum Capacity: Up to 128GB
• Supported Memory Types: DDR5 (up to 6400 MHz overclocked)
• Memory Architecture: Dual Channel with support for ASUS Enhanced Memory Profile (AEMP II).

Expansion Slots:

• 2 x PCIe 5.0 x16 slots for high-performance graphics cards.
• 1 x PCIe 4.0 x16 slot (operating at x4 mode).

Storage Options:

• M.2 Slots:
  • 3 x M.2 sockets supporting PCIe and SATA modes.
• SATA Ports:
  • 6 x SATA III (6Gb/s) ports with RAID support.

Networking:

• Ethernet:
  • 1 x Marvell® AQtion 10Gb Ethernet
  • 1 x Intel® 2.5Gb Ethernet with ASUS LANGuard.
• Wi-Fi: Integrated Wi-Fi 6E for enhanced wireless connectivity.

USB Connectivity:

• Rear USB Ports:
  • 1 x USB 3.2 Gen 2x2 Type-C
  • 1 x USB 3.2 Gen 2 Type-C
  • 4 x USB 3.2 Gen 2 Type-A
  • 2 x USB 3.2 Gen 1 Type-A
  • 2 x USB 2.0 Type-A

Audio Features:

• Audio Codec: Supports up to 8-channel high-definition audio.

Additional Features:

• Thunderbolt™ Support: Two Thunderbolt™ 4 ports (USB4 compliant) for high-speed data transfer up to 40 Gbps.
• AI Overclocking: Automatically optimizes CPU performance based on system conditions.
• Comprehensive Cooling Solutions: Includes multiple heatsinks for VRMs and M.2 slots to prevent thermal throttling.
• ASUS Aura Sync RGB for customizable lighting effects.
