ASUS ROG Strix Z790-E Gaming WiFi Motherboard - LGA 1700, Intel Z790, DDR5, PCIe 5.0, Wi-Fi 6E

The ASUS ROG Strix Z790-E Gaming WiFi motherboard is designed for gamers and enthusiasts looking to maximize their performance with Intel's latest processors. Built on the Intel Z790 chipset, this ATX motherboard supports both 12th and 13th Generation Intel Core processors, offering a blend of advanced features and robust connectivity options.

Key Features:

• Socket Type: LGA 1700
• Chipset: Intel® Z790
• Form Factor: ATX (30.5 x 24.4 cm)

CPU Support:

• Compatible with Intel® 12th and 13th Generation Core™, Pentium Gold, and Celeron processors.
• Supports Intel® Turbo Boost Technology 2.0 and Turbo Boost Max Technology 3.0.

Memory Support:

• Slots: 4 x DIMM
• Maximum Capacity: Up to 128GB
• Supported Memory Types: DDR5 (up to 7200 MHz overclocked)
• Memory Architecture: Dual Channel with ASUS Enhanced Memory Profile II (AEMP II) for optimized performance.

Expansion Slots:

• 1 x PCIe 5.0 x16 slot for high-performance graphics cards.
• 2 x PCIe 4.0 x16 slots (operating at x4 mode).
• 1 x PCIe 3.0 x1 slot for additional expansion cards.

Storage Options:

• M.2 Slots:
  • 5 x M.2 sockets supporting PCIe and SATA modes.
• SATA Ports:
  • 4 x SATA III (6Gb/s) ports with RAID support.

Networking:

• LAN Controller: Integrated Intel® 2.5Gb Ethernet for high-speed wired connectivity.
• Wi-Fi: Integrated Wi-Fi 6E (802.11ax) for enhanced wireless performance.
• Bluetooth: Bluetooth 5.2 support for wireless peripherals.

USB Connectivity:

• Multiple USB ports including:
  • Two USB 3.2 Gen 2x2 Type-C ports for fast data transfers up to 20 Gbps.

Audio Features:

• Audio Codec: Realtek ALC4080 with high-fidelity audio output supporting up to 7.1 channels.

Additional Features:

• AI Overclocking: Automatically profiles CPU and cooling to predict optimal configurations for enhanced performance.
• Robust Power Delivery: Features an advanced power design with an 18+1 power stage setup to handle demanding workloads.
• Comprehensive Cooling Solutions: Includes substantial heatsinks and multiple fan headers for optimal thermal management.
• Customizable RGB Lighting: Aura Sync RGB lighting integrated into the design for personalized aesthetics.
