MSI PRO Z890-P WIFI Motherboard - LGA 1851, DDR5, PCIe 5.0, ATX

The MSI PRO Z890-P WIFI Motherboard is designed for high-performance computing, supporting Intel's Core Ultra Processors (Series 2) with the LGA 1851 socket. This ATX motherboard features the advanced Intel Z890 chipset and is equipped with cutting-edge technologies tailored for professionals and gamers.Key Features:

• Processor Compatibility:
  • Supports Intel® Core™ Ultra Processors (Series 2) using the LGA 1851 socket.
• Chipset:
  • Intel Z890 chipset for enhanced performance.
• Memory Support:
  • Slots: 4 x DDR5 UDIMM slots
  • Maximum Capacity: Up to 256GB
  • Speed Support:
    • Supports DDR5 memory speeds from 9200 MT/s (OC) down to 6400 MT/s (JEDEC), accommodating various configurations:
      • 1DPC 1R: Up to 9200+ MT/s
      • 1DPC 2R: Up to 7200+ MT/s
      • Dual-Channel support.
• Expansion Slots:
  • PCIe Slots:
    • 3 x PCIe x16 slots (one PCIe 5.0 and two PCIe 4.0)
    • 1 x PCIe x1 slot.
• Storage Options:
  • M.2 Slots:
    • 4 x M.2 slots supporting PCIe Gen5 and Gen4 for high-speed NVMe SSDs.
    • SATA Ports: 4 x SATA III (6Gb/s) ports, with RAID support for SATA and NVMe configurations.
• Networking:
  • LAN Controller: Realtek® RTL8126 providing 5Gbps LAN for reliable wired connectivity.
  • Wi-Fi: Integrated Intel® Wi-Fi 7 solution offering speeds up to 5.8Gbps, along with Bluetooth 5.4 support.
• Audio Features:
  • Realtek® ALC897 Codec providing high-definition audio quality with support for up to 7.1-channel audio.

Advanced Features

• Power Delivery System:
  • Features a robust power delivery system with a Duet Rail Power System designed to handle demanding CPU loads effectively.
• Premium Thermal Solution:
  • Extended heatsink design with MOSFET thermal pads rated at 7W/mK and EZ M.2 Shield Frozr technology to prevent thermal throttling during intensive workloads.
• Thunderbolt Connectivity:
  • Includes a Thunderbolt™ 4 port supporting up to 40Gbps transfer rates for fast data transmission and connectivity.

Design and Build Quality

The PRO Z890-P WIFI features a durable ATX form factor that ensures efficient heat dissipation while providing ample space for high-performance components. Its robust construction guarantees stability and longevity in demanding environments.
