MSI PRO Z890-S WIFI Motherboard - LGA 1851, DDR5, PCIe 5.0, ATX

The MSI PRO Z890-S WIFI Motherboard is engineered to support Intel's Core Ultra Processors (Series 2) using the LGA 1851 socket. This ATX motherboard features the advanced Intel Z890 chipset and is equipped with a range of cutting-edge technologies designed for both gamers and professionals.

Key Features:

• Processor Compatibility:
  • Supports Intel® Core™ Ultra Processors (Series 2) with LGA 1851 socket.
• Chipset:
  • Intel Z890 chipset for enhanced performance.
• Memory Support:
  • Slots: 4 x DDR5 UDIMM slots
  • Maximum Capacity: Up to 256GB
  • Speed Support:
    • Supports DDR5 memory speeds from 8600 MT/s (OC) down to 6400 MT/s (JEDEC), accommodating various configurations:
      • 1DPC 1R: Up to 8600+ MT/s
      • 1DPC 2R: Up to 7200+ MT/s
      • Dual-channel configuration support.
• Expansion Slots:
  • PCIe Slots:
    • 4 x PCIe x16 slots (one PCIe 5.0, one PCIe 4.0, and two PCIe 3.0).
• Storage Options:
  • M.2 Slots:
    • Multiple M.2 slots supporting PCIe Gen5 for high-speed NVMe SSDs.
    • SATA Ports: Several SATA III (6Gb/s) ports for traditional storage devices.
• Networking:
  • LAN Controller: Realtek® RTL8125D providing 2.5Gbps LAN for reliable wired connectivity.
  • Wi-Fi: Integrated Intel® Wi-Fi 7 solution with support for dual-band frequencies (2.4GHz / 5GHz / 6GHz) and Bluetooth 5.4.
• Audio Features:
  • Realtek® ALC897 Codec providing high-definition audio quality with support for up to 7.1-channel audio.

Advanced Features

• Thunderbolt Connectivity:
  • Includes a Thunderbolt™ 4 port supporting up to 40Gbps transfer rates and daisy-chaining capabilities for multiple devices.
• Enhanced Power Design:
  • Features a robust power delivery system designed to handle demanding CPU loads effectively.
• Premium Thermal Solution:
  • Extended heatsink design with M.2 Shield Frozr technology to prevent thermal throttling during intensive workloads.

Design and Build Quality

The PRO Z890-S WIFI features a sleek ATX form factor that ensures efficient heat dissipation while providing ample space for high-performance components. Its durable construction guarantees stability and longevity in demanding environments.
