TP-Link EAP225 Outdoor AC1200 Wireless MU-MIMO Access Point

The TP-Link EAP225 is a versatile AC1200 dual-band outdoor access point designed to provide reliable and high-speed Wi-Fi coverage in outdoor environments. With its advanced features, including MU-MIMO technology and robust weatherproof design, the EAP225 is ideal for various applications such as parks, campuses, and large outdoor venues.

Key Features

• High-Speed Dual-Band Performance:
  • Supports simultaneous dual-band speeds of up to 1200Mbps (300Mbps on 2.4GHz and 867Mbps on 5GHz), ensuring fast and stable connections for multiple users.
• MU-MIMO Technology:
  • Equipped with the latest 802.11ac Wave 2 MU-MIMO technology, allowing the access point to communicate with multiple clients simultaneously, optimizing network performance in high-density environments.
• Weatherproof Enclosure:
  • The EAP225 features an IP65-rated enclosure, providing protection against dust and water, making it suitable for outdoor installations.
• Power over Ethernet (PoE) Support:
  • Supports both 802.3af PoE and 24V Passive PoE, allowing for flexible installation options without the need for additional power sources. A PoE injector is included for convenience.
• Centralized Management:
  • Compatible with TP-Link’s Omada Controller software, enabling centralized management of multiple access points for easy monitoring and configuration.
• Multiple SSIDs and VLAN Support:
  • Allows the creation of up to 16 SSIDs, facilitating network segmentation for different user groups or purposes. It also supports VLAN tagging for enhanced network management.

Technical Specifications

• Model: TP-Link EAP225
• Wireless Standards: IEEE 802.11a/b/g/n/ac
• Frequency:
  • 2.4GHz: Up to 300Mbps
  • 5GHz: Up to 867Mbps
• Antenna Configuration:
  • 2 x 3dBi antennas for 2.4GHz
  • 2 x 4dBi antennas for 5GHz
• Ports:
  • 1 x Gigabit Ethernet (RJ-45) port (supports PoE)
• Power Supply:
  • Passive PoE (+4,5 pins; -7,8 pins), PoE adapter included
• Power Consumption:
  • Maximum of 10.5 Watts
• Dimensions:
  • Approximately 215 x 46 x 27 mm (8.5 x 1.8 x 1.1 in)

Performance Features

• Wireless Client Capacity:
  • Supports over 220 concurrent clients, making it ideal for high-density environments.

Environmental Specifications

• Operating Temperature:
  • Ranges from 0°C to +40°C (32°F to +104°F)
• Storage Temperature:
  • Ranges from -40°C to +70°C (-40°F to +158°F)
• Operating Humidity:
  • Humidity levels of 10% to 90% non-condensing
