TP-Link VIGI NVR4032H 32-Channel Network Video Recorder

The TP-Link VIGI NVR4032H is a powerful 32-channel network video recorder designed for comprehensive surveillance solutions. With its advanced features, high decoding capacity, and robust storage options, this NVR is ideal for both residential and commercial security applications.

Key Features

• 32-Channel Input:
  • Supports up to 32 IP cameras, allowing for extensive coverage and monitoring capabilities.
• Decoding Capacity:
  • Capable of decoding 16 channels at 2MP or 8 channels at 4MP, enabling simultaneous live viewing and playback.
• High Definition Recording:
  • Supports recording resolutions up to 8MP, ensuring clear and detailed footage.
• Mass Storage:
  • Supports up to 4 SATA drives, with each drive capable of holding up to 10TB, providing ample storage for recorded video data.
• H.265+ Video Compression:
  • Utilizes H.265+ compression technology to transmit crystal-clear video without using extra bandwidth, saving disk space and reducing monitoring costs.
• 320 Mbps Bandwidth:
  • Ensures high performance with both incoming and outgoing bandwidth of up to 320 Mbps, allowing the NVR to manage multiple high-resolution cameras efficiently.
• Multiple Video Outputs:
  • Features one HDMI and one VGA interface for independent video output, supporting various resolutions including 3840x2160 at 30Hz.
• Remote Monitoring:
  • Compatible with the VIGI app and web UI for remote access and monitoring, providing ease and convenience for users.

Specifications

• Video Input:
  • 32-channel IP video input.
• Video Output:
  • HDMI (supports up to 4K) and VGA outputs.
• Audio Compression:
  • G.711A/G.711U/G.726.
• Recording Modes:
  • Manual recording, scheduled recording, and motion detection recording.
• Playback Modes:
  • Instant playback, regular playback, tag playback, event playback.
• Operating Temperature:
  • Functions effectively within a temperature range of -10°C to 55°C.
• Dimensions:
  • Approximately 440 x 330 x 44 mm.
• Weight:
  • Approximately 4.0 kg (net weight).

Connectivity

• Network Interface:
  • Dual Ethernet ports for network redundancy and load balancing.
• USB Ports:
  • Two USB 2.0 ports for connecting peripherals such as a mouse or external storage devices.

Package Contents

• TP-Link VIGI NVR4032H Network Video Recorder
• Power Adapter
• Quick Installation Guide
